Page 80
SW046 Ladder Scan Time Read only Value is multiple of 0.1 mSec
S0034 Ladder Instruction Error
Status
Read/Write Set if Division by zero operation is performed in
the ladder instruction and for invalid conditions or
operands in case of conversion instructions.
Configuration Words and coils
Register / Coil Tag Name Read / Write Description
MW0000 PLC Operation Mode
(Bit 0 to Bit 3)
Read/Write Bit0-3: 0: Initialization 1: HALT Mode 2: RUN
Mode 3: RUN-F Mode 4: HOLD Mode 6: ERROR
Mode.
MW0001 Error Register 1 Read Only Refer mapped coils M16 to M31
MW0002 Error Register 2 Read Only Refer mapped coils M32 to M47
MW0003 RUN/STOP Switch Control
(Retentive)
Read Only 1: HALT, 0: RUN. Only LSB is used. other bits (1
to 15) are not used.
MW0005 Digital Filter constant Read/Write Enabled when MW10 bit 16 is ON.
(0 to 15 mS)
MW0010 Configuration Register for
Special inputs
Read/Write Refer Special input - output section
MW0011 Configuration Register for
PWM output
Read/Write Refer Special input - output section
MW0012 Preset values for high Speed
Counter
Read/Write Used to set the preset values for high speed
counter MW0013
MW0014
MW0015
MW0016 Count Values for high Speed
Counter
Read/Write Preset count values of the high speed counters
are stored
MW0017
MW0018
MW0019
MW0020 High Speed counter
control flags Read/Write Control flags for high speed counters
MW0021 Special output control flags Read/Write Refer Special input - output section
MW0022 Special Output Control Flags Read/Write Control flags for high speed counters
MW0023
MW0024 Special output Frequency
Setting
Read/Write Refer Special input - output section
MW0025
MW0030 System Timer Coils Read Only Refer mapped coils M00480 to M00487
MW0031 User Interrupt program Status
Flags
Read Only Bit 0 for timer ,Bit 1 for IO1, Bit 2 for IO2. Refer
mapped coils M496,M497 & M498
when MW10 bit 16 is ON.
MW0033 Unit IP Address Lo Word Read Only Used for Ethernet Model
MW0034 Unit IP Address Hi Word Read Only
MW0035 Unit Subnet Mask Address
Lo Word
Read Only
MW0036 Unit Subnet Mask Address
Hi Word
Read Only
MW0037 Unit Default Gateway
Lo Word
Read Only
MW0038 Unit Default Gateway
Hi Word
Read Only
M00016 CPU error Read Only ON at error state
M00017 I/O error Read Only ON at error state
M00018 Program error Read Only ON at error state. This group includes Ladder
Scan time.
