7.2 Memory Allocation of XW, YW and MW
Memory for XW, YW and MW registers for particular model is allocated by software at the time of I/O allocation. The
number of XW, YW and MW for the particular model is as per the table given below:
Sr.
No.
Model Name
Description
XW
YW
MW
X
Y
1
GPU288
V200 Base Model
1
1
60
8
8
2
GPU200
V200 Base Module with Ethernet
0
0
60
0
0
3
GDI216
16 Input Digital Module
1
0
0
16
0
4
GDO216P
16 PNP type transistor output digital module
0
1
0
0
16
5
GDO216N
16 NPN type transistor output digital module
0
1
0
0
16
6
GRO216
16 Relay type output digital module
0
1
0
0
16
7
GDD216P
8 Digital input, 8 PNP type transistor output digital
module
1
1
0
8
8
8
FLD0808N
8 Digital input, 8 NPN type transistor output digital
module
1
1
0
8
8
9
GDR216
8 Digital input, 8 Relay type output digital module
1
1
0
8
8
10
GAD208L
0-10 VDC or 4-20 mA (16 Bit) 8 channel input model
8
0
50
0
0
11
GDA204
0-10 VDC or 4-20 mA (16 Bit) 4 channel output model
0
4
30
0
0
12
GRT208
PT100 RTD (16 Bit) 8 channel input model
8
0
50
0
0
13
GAA242
4 Universal Analog Inputs ( RTD, TC, 4-20 mA,
0-20mA,0-50mV, 0-100mV, 0-10VDC) (16 Bit),
2 channel Voltage/Current (16 Bit) outputs.
4
2
40
0
0
The allocation is sequential. If any particular model does not have XW / YW / MW defined then the memory is not
allocated in the array for that model. This array is sequentially mapped to Modbus registers.
Consider the example that user has configured the models as below:
Slot 0 :
GPU288
:
XW : 1,
YW : 1,
MW : 60
Slot 1 :
GDR288
:
XW : 1,
YW : 1,
MW : 0
Slot 2 :
GRO216
:
XW : 0,
YW : 1,
MW : 0
Slot 3 :
GDD288N
:
XW : 1,
YW : 1,
MW : 0
Slot 4 :
GDI216
:
XW : 1,
YW : 0,
MW : 0
Slot 5 :
GAD208L
:
XW : 8,
YW : 0,
MW : 50
