9 communication cables, Communication cables – Toshiba Programmable Logic Controller V200 User Manual
Page 71
Page 63
Pin#
Signals
1
TXD
2
RXD
3
SG & Shield
4
5
6
7
8
9
Signals
Pin#
1
RXD
2
TXD
3
4
SG & Shield
5
6
7
8
9
PC
E
nd
2.9 Communication Cables
Programming cable for V200 PLCs (IBM-H-005-00):
PC SIDE
V200 SIDE
2 mtr.
FRONT VIEW
Pin 1
R.H.S. VIEW
Pin 8
(Left side)
(Right side)
5
1
9
6
DB9 FEMALE PINOUTS
8
MODULAR CONNECTOR PINOUTS
