Toshiba Programmable Logic Controller V200 User Manual
Page 112
Page 104
No
"Device/“register"
Name
Function
1
M0016
CPU error (down)
ON at error state
2
M0017
I/O error
ON at error state
3
M0018
Program error (down)
ON at error state
4
M0019
Not Used
5
M0020
Not Used
6
M0021
"Clock/calendar error“(alarm)"
ON when clock/calendar data is illegal
7
M0022
"Retentive data invalid“(alarm)"
ON when retentive data in RAM are invalid
8
M0023
Not Used
9
M0024
Not Used
10
M0025
Not Used
11
M0026
Not Used
12
M0027
"Watchdog timer error“(down)"
ON at error state
13
M0028
Not Used
14
M0029
I/O mismatch (down)
ON at error state
15
M0030
Analog Power Fail (Alarm)
ON at error state
16
M0031
BCC error (down)
ON at error state
17
M0032
Not Used
18
M0033
Scan time over (down)
ON when the scan time exceeds 200 ms
19
M0034
Not Used
20
M0035
Not Used
21
M0036
Not Used
22
M0037
Not Used
23
M0480
System timer coil for 0.1 sec interval
24
M0481
System timer coil for 0.2 sec interval
25
M0482
System timer coil for 0.4 sec interval
26
M0483
System timer coil for 0.8 sec interval
27
M0484
System timer coil for 1 sec interval
28
M0485
System timer coil for 2 sec interval
29
M0486
System timer coil for 4 sec interval
30
M0487
System timer coil for 8 sec interval
31
M0496
Timer interrupt execution status
ON when Timer program is executing
32
M0497
IO1 interrupt execution status
ON when IO1 program is executing
33
M0498
IO2 interrupt execution status
ON when IO2 program is executing
34
M0504
Hold mode status
On when PLC is in hold mode.
35
M0512
ALWAYS ON
36
M0513
ALWAYS OFF
