Toshiba Programmable Logic Controller V200 - Manual (Page 38)

Page 30
SW2
SW3
SW4
SW5
SW6
SW7
SW8
+
Wiring Diagram for Digital I/Ps and O/Ps of model V288*3S CPU:
1. Wiring diagram for testing digital inputs:
Note: X0 and X1 are high speed input
SW1 X0
X1
X2
X3
X4
X5
X6
F
L
X7
C
0
- 1
24VDC
0
Closing Swx will turn on respective inputs
Wiring for transistor type outputs:
Transistor
type O/P
Y1
24VDC
24VDC
LOAD Internal
Circuit
- F
Y2
L
LOAD Internal
Circuit
0
1
0
