Page 103

6 INTERNET FAX
Viewing Touch Panel for Fax Menu 101
Viewing Touch Panel for Fax Menu
1. Message Display Area
Operational instructions and the status of the equipment are displayed.
2. [SINGLE] Tab
On this tab, you can select individual contacts and various function buttons relevant to Internet faxing operation.
3. [GROUP] Tab
On this tab, you can select groups of contacts and various function buttons relevant to Internet faxing operation.
4. [ADDRESS] Tab
This tab contains contacts information saved in the equipment’s address book and displays the information on the
[SINGLE] and the [GROUP] tab.
5. [ADVANCED] Tab
On this tab, various kinds of advanced functions are available for you.
P.111 “Setting advanced functions”
6. Alert Message Display Area
Alert messages are displayed when the equipment needs a toner cartridge replacement, the waste toner box needs
cleaning, etc. For details on these messages, refer to the Troubleshooting Guide.
7. Date and Time
When you press the [FAX] button on the control panel, the FAX menu is
displayed on the touch panel.
If the equipment is managed by the Department Management or
User Management features, you need to enter a department code
or the user information, such as the user name and password.
1
11
7
9
2
5
8
10
3
4
6
