G7 ASD Multi-Protocol Communication Option and PG Feedback Option Manual 55
11.5.4.5.1 Output Instance 20 (Basic Speed Control Output)
This is the ODVA AC/DC Drive Profile Basic Speed Control Output assembly. For more information,
refer to the
ODVA DeviceNet Specifications and the object explanations in this manual related to each of
the fields of this assembly instance.
Byte # Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Fault Reset Run Fwd
1
2 Speed Reference (Low Byte)
3 Speed Reference (High Byte)
11.5.4.5.2 Output Instance 21 (Extended Speed Control Output)
This is the ODVA AC/DC Drive Profile Extended Speed Control Output assembly. For more
information, refer to the
ODVA DeviceNet Specifications and the object explanations in this manual
related to each of the fields of this assembly instance.
Byte # Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 NetRef NetCtrl Fault Reset Run Rev Run Fwd
1
2 Speed Reference (Low Byte)
3 Speed Reference (High Byte)
