G7 ASD Multi-Protocol Communication Option and PG Feedback Option Manual
30
Input Terminals
Bit-mapped input terminal word internally located at parameter 0xFE06. Table 18 provides the format
of this input terminal word.
Table 18: Input Terminals
Bit
Terminal Name
(Expansion Terminals)
Function
Parameter
Number
0 1
15
(B15)
Input terminal selection 16
F126
OFF
ON
14
(B14)
Input terminal selection 15
F125
OFF
ON
13
(B13)
Input terminal selection 14
F124
OFF
ON
12
(B12)
Input terminal selection 13
F123
OFF
ON
11
(B11)
Input terminal selection 12
F122
OFF
ON
10
(B10)
Input terminal selection 11
F121
OFF
ON
9
(B9)
Input terminal selection 10
F120
OFF
ON
Hi
gh
B
yte
8
(B8)
Input terminal selection 9
F119
OFF
ON
7
S4
Input terminal selection 8
F118
OFF
ON
6
S3
Input terminal selection 7
F117
OFF
ON
5
S2
Input terminal selection 6
F116
OFF
ON
4
S1
Input terminal selection 5
F115
OFF
ON
3
RES
Input terminal selection 4
F114
OFF
ON
2
ST
Input terminal selection 3
F113
OFF
ON
1
R
Input terminal selection 2
F112
OFF
ON
Lo
w
By
te
0
F
Input terminal selection 1
F111
OFF
ON
• Response Bits / Parameter Number (Offsets 32 ∼∼∼∼ 35)
Parameter response bits and 16-bit parameter number. Refer to section 9.6 for a detailed explanation of
these items.
• Parameter Data (Offsets 38 and 39)
During parameter reads, this word contains the requested data response. Refer to section 9.6 for a
detailed explanation of this location.
