9.6.2 Parameter Number / Action Input Words
The response by the Multicom interface to parameter read and write requests is placed in 2 input words
and 2 input bits of the input data structure. The structure of these data items is as follows:
Response Bits
Bit #: 15 14 13 12 11 8 7 4 3 0
Re
se
rv
ed
Re
se
rv
ed
R
es
p1
R
es
p0
Action response bits
(offset 32)
Reserved (offset 33)
Parameter Number Response Word
Bit #: 15 12 11 8 7 4 3 0
Parameter number response high byte
(offset 34)
Parameter number response low byte
(offset 35)
Parameter Data / Error Code Response Word
Bit #: 15 12 11 8 7 4 3 0
Parameter data response
high byte (offset 38)
Parameter data response
low byte (offset 39)
Note that all locations marked “Reserved” are set to 0 by the Multicom interface.
Parameter data / error code
Reserved
Parameter number
