7. LED Indicators
This section applies to ASD-MULTICOM-A option boards only.
The interface board contains two bi-color red/green status LEDs. The lower LED indicates the Module
Status (MS), and the upper LED indicates the Network Status (NS). Refer to Figure 2. The use and
context of these LEDs is network-specific: refer to each network’s section in this manual for further
information.
NS (Network Status)
MS (Module Status)
PCB
Figure 2: LED Indicators
