Using the Menus

1760 Series Component Waveform/Vector Monitor User Manual

3-23

OFFSET

H The

VERTICAL POSITION

control normally positions

all channels together. When

OFFSET

is enabled, the

bezel controls can be used to offset input channels 2

(

)

and 3

(

)

with respect to channel 1

(

)

H While the offsets are enabled, the

VERTICAL POSI-

TION

control will still position all channels together,

with the offset amount remaining constant. When

OFFSET

is turned off, the input channels will be

re-aligned. The selected offset amount will be
recalled the next time

OFFSET

is enabled.

H When

A2A3 OFFSET

is on, the center and right bezel

controls are assigned to

CH A2

and

CH A3

offsets.

On-screen labels appear just above each control.
Turning these controls will offset the

CH A2

and

signals with respect to

CH A1

When

B2B3

offset

is on, the same two controls are assigned to

CH B2

and

CH B3.

H When both

A2A3

and

B2B3

offsets are on, the user

assigns the controls to either

offsets. The

CONTROL

selection only appears when both

and

OFFSETS

are selected.

H An offset will remain in effect until the user turns

the offset

OFF.

(Exiting the

CONFIG

menu will not

affect the

OFFSET ON / OFF

setting.)
