At A Glance
1760 Series Component Waveform/Vector Monitor User Manual
2-5
H
TIME CODE
provides monitoring of longitudinal
time code in a frame-rate display.
H
MULTIPLE
allows simultaneous selection of
WAVE-
FORM
and
VECTOR DISPLAY
modes.
SWEEP
Sweep buttons are used to select the waveform sweep rate.
H
LINE/FIELD
toggles through four sweep rate selec-
tions: one line, two line, one field, and two field.
Two line and two field selections not available with
PARADE
or
A123
or
B123
display.
H
MAG
turns on the sweep magnifier. See page 3-6.
DC REST
H
RESTORE
turns the DC Restorer on or off. Set DC
restorer speed and clamp point through the
CON-
FIGURE
menu, shown on page 3-20.
REF
H
EXT
toggles between external (
EXT
LED on) and
internal reference. Internal reference can be config-
ured for component operation, and two external
reference inputs can be designated for dual-standard
instruments. See
CONFIGURE
menu on page 3-20.
INPUT
H Selecting a front-panel input causes the signal that is
input to the corresponding rear-panel connector to
be displayed on screen.
