1760 Series Component Waveform/Vector Monitor User Manual x
Figure 4-1 NTSC waveform/vector graticule 4-2 . . . . . . . . . .
Figure 4-2 PAL waveform/vector graticule 4-3 . . . . . . . . . . . .
Figure 4-3 Dual Standard waveform/vector graticule 4-4 . . . .
Figure 4-4 Vector targets 4-7 . . . . . . . . . . . . . . . . . . . . . . . .
Figure 4-5 Differential gain and phase measurements 4-9 . . .
Figure 4-6 NTSC dual-dot SCH display 4-11 . . . . . . . . . . . . .
Figure 4-7 NTSC single-dot SCH display 4-11 . . . . . . . . . . . .
Figure 4-8 PAL SCH display 4-12 . . . . . . . . . . . . . . . . . . . . .
Figure 4-9 Two-Line SCH R--Y display (NTSC), with
proper SC/H phase
4-13 . . . . . . . . . . . . . . . . . . . .
Figure 4-10 Two-Field SCH R--Y display (NTSC), showing
proper SC/H phase
4-13 . . . . . . . . . . . . . . . . . . . .
Figure 4-11 Two-Field SCH R--Y display (NTSC), showing
approximate 10
° phase error
4-14 . . . . . . . . . . . . .
Figure 4-12 Two-Field SC/H R--Y display (PAL), showing
proper SC/H phase
4-14 . . . . . . . . . . . . . . . . . . . .
Figure 4-13 Audio displays 4-15 . . . . . . . . . . . . . . . . . . . . . . .
Figure 4-14 Lightning display showing correct timing 4-16 . . . . .
Figure 4-15 Lightning display showing delay 4-18 . . . . . . . . . . .
Figure 4-16 Diamond display showing signal inside
gamut limits
4-19 . . . . . . . . . . . . . . . . . . . . . . . . .
Figure 4-17 Bowtie display showing a sharp null 4-21 . . . . . . . .
Figure B-1 Rear panel REMOTE connector B-1 . . . . . . . . . . .
Figure B-2 Using the 1760--Series as a 1740 / 1750--Series
replacement
B-4 . . . . . . . . . . . . . . . . . . . . . . . . .
Figure B-3 Rear panel RS232 connector B-5 . . . . . . . . . . . . .
Figure C-1 Graticule light replacement C-3 . . . . . . . . . . . . . .
