Operator’s Checkout Procedure

1760 Series Component Waveform/Vector Monitor User Manual

2-22

Line Selection

Line select is available in

WAVEFORM, VECTOR, SCH

, and


display modes. Enter the

LINE SELECT

menu and

turn the center bezel control until the readout displays

ALL

131

. In a two line display, line 131 appears on the left,

followed by line 132.

Select

2 FIELD

sweep and note the intensified line in each

field. Select

15H

and note that 15 lines are now intensified

in each field (intensified portion appears wider). The
readout is now

ALL 131---- 145

. See Figure 2-13.

Select

1 of2

. Now only the first field has intensified lines,

and a

NEXT FIELD

selection appears. Select

NEXT FIELD

and

note that the intensified lines now appear only in the second
field and the readout is

F2 131 F2 145.

Select

MULTIPLE

with

WAVEFORM, VECTOR,

and

SCH

. Note

that the displays appear in the following order:

WAVEFORM,

VECTOR, SCH.

Exit the line select menu. Enter the menu again and note
that the user settings are unchanged. Exit the menu.

LINE SEL

ALL131

FIELD

ALL 1OF2

1OF8

1OF4

15H

-- -- 145

Figure 2-13. Line Select display with 15H selected, in 2 FIELD sweep.
