1760 Series Component Waveform/Vector Monitor User Manual
I ---2
D
DC restorer, 2-5
slow or fast, 3-20
Diamond Display, 4-18
Differential gain measurements, 4-8
Differential phase measurements, 4-8
Differentiated step filter, 3-9
Dimensions, A-14
Display modes, 2-4, 3-1
Dual-standard graticule, 4-7
E
Electrical installation, 1-10
Electrical specification, A-2
Environmental Characteristics, Specifica-
tion, A-14
External horizontal, 3-25
External reference, 2-5, 2-8
configure, 3-25
Specification, A-5
for dual-standard monitors, 3-25
F
Factory preset, 3-18
Fan filter
cleaning or replacing, C-1
part number, 1-7
Field sweeps, 2-5
Field upgrade kits, 1-8
Filter, air, see fan filter, 1-7
Focus, 3-27
Front-panel controls, 2-1
Front-panel cover , 1-7
Fuse
part number, 1-7
replacing, C-1
G
Gain
adjustment, 4-23
menu, 3-26
reset, 3-24, 3-25
X1, X5, X10, 3-26
Graticule
illumination, 3-27
vector, 4-6
waveform, 4-1
Graticule lights
part number, 1-7
replacement, C-2
H
HAD bar, 4-5
Horizontal Deflection, Specification, A-5
I
Input channels, 2-6, 3-5
Input connectors, 2-8
Input coupling, 3-20
Installation, 1-9
electrical, 1-10
mechanical, 1-12
remote connector, 1-11
Intensity adjustment, 1-15, 3-27
K
K-factor measurements, 4-5
