1760 Series Component Waveform/Vector Monitor User Manual
2-1
At A Glance
Front-Panel Controls
This overview of front-panel controls refers to Figure 2-2.
Controls---Switches---LEDs
H All front-panel controls are the continuous action
type, and all front-panel buttons are push and release
toggle switches.
H Green LEDs light to indicate the current switch
selection.
POWER
H
ON/STANDBY turns the instrument on or to standby
status. An LED indicates when power is on.
WARNING
If an appropriate power source is supplied to this instru-
ment, line voltage will be present, even when in
STANDBY
mode. Do not operate the instrument without a cabinet or
rack adapter such as those described on page 1-8; serious
injury could result.
Instrument Reset
Certain conditions may cause the 1760--Series instrument
front-panel controls to become locked. Reset as follows:
H Turn off instrument power.
