At A Glance
1760 Series Component Waveform/Vector Monitor User Manual
2-7
H PRESET allows the user to store and recall up to 9
front-panel setups. One additional recall is factory
pre-programmed. Presets one through eight can also
be accessed remotely.
H CONFIG allows the user to configure several operat-
ing parameters, such as input coupling, dc restorer
speed, and internal reference designation.
H GAIN provides selection of X1, X5, X10 , and variable
gain.
H CRT menu allows adjustment of CRT focus, signal
intensity, and trace rotation.
H CLEAR MENU turns off the selection portions of the
menu readout. When CLEAR MENU has been used to
clear a menu readout, push the menu button once to
reinstate the readout, and once again to exit the
menu.
