Appendix A: Performance Specification
A-12
1760 Series Component Waveform/Vector Monitor User Manual
Table A- 11: Component Vector Mode (Cont.)
CATEGORY DESCRIPTION
Display to Graticule
Registration Req: ≤0.25 box with the color bar black display dot
centered in target
Vector Display RI: Ch A2 or B2 is displayed on the horizon-
tal axis and Ch A3 or B3 is displayed on
the vertical axis.
Table A- 12: Lightning Mode
CATEGORY DESCRIPTION
Vertical Gain Accuracy Req: ±2%
RI: With respect to electronic graticule
Horizontal Gain Accuracy Req: ±2%
RI: With respect to electronic graticule
Electronic Graticule Display RI: Ch A1 or B1 is displayed vertically.
Ch A2 or B2 is displayed horizontally on
top half of display.
Ch A3 or B3 is displayed horizontally on
bottom half of display.
Table A- 13: Bowtie Mode
CATEGORY DESCRIPTION
Common Mode Rejection
Ratio Req: ≥34 dB at 3 MHz
RI: Timing error contributed by the
specification limit will be less than
0.6 ns.
Electronic Graticule Display RI: Y minus P B (CH1-- CH2) is displayed on
the left half of the display.
Y minus P
R (CH1-- CH3) is displayed on
the right half of the display.
