Product Description
1760 Series Component Waveform/Vector Monitor User Manual
1-3
erator selects a menu item, such as VOLTAGE/TIMING CUR-
SORS , VARIABLE GAIN , or LINE SELECT , an on-screen label
shows the current function of the controls.
Instrument configurations such as dc restorer speed and
clamp timing are made through an on-screen menu in the
1760--Series. The
FILTER menu also provides a choice of four
filters in addition to flat.
CRT
The monitors have a bright, post-accelerated CRT with
lighted internal graticule. The parallax-free internal graticule
structure contains targets and markings for both the vector
and waveform functions. A white phosphorus CRT is option-
al; refer to page 1-6 for details.
The bright CRT allows use in high ambient light conditions,
such as those encountered in field production applications.
Calibrator
Vertical and horizontal instrument gain can be set using the
calibrator signal. The 1 Volt calibrator signal is available in
100 kHz and F
sc (color subcarrier) rates.
More Information
H Standard and optional accessories are listed in the
Accessories section, which follows this product descrip-
tion.
H Instrument options are listed on page 1-5.
H A complete listing of instrument specifications begins on
Appendix page A-1.
