OUTPUT SEL
OUTPUT SEL
O U T P U T – S E T T I N G S E L E C T O U T P U T C H
Output channel selection
O U T 1 – _ _ _ _ _ _ _
Output channel 1 name setting
OUTPUT SEL
O U T 2 – _ _ _ _ _ _ _
Output channel 2 name setting
OUTPUT SEL
OUTPUT SEL
O U T 3 – _ _ _ _ _ _ _
Output channel 3 name setting
OUTPUT SEL
O U T 8 – _ _ _ _ _ _ _
Output channel 8 name setting
(For the channel on which the T-001T is used)
Setting menu screen
UTILITY MEMORY
Normal use state
PARAMETER
Press for over 2 seconds.
ESC/BACK
Output channel 1 name setting
Note
Any output channel name setting screen can
return to the output channel selection screen
using the Escape/Back key.
Note
When the 1-channel output operation is selected
for the operation method, only Output channel 1
can be set. The name setting screen for Output
channel 2 does not appear.
13.5.1. Setting flow chart
The screen display examples shown below may differ from actual displays.
The on-screen indications shown in red here (actually shown by flashing cursors) are parameters or setting
contents to be selected with the Parameter setting knob, input channel selection key or other designated keys.
The indications of the [ ], [ ], [
], and [ ] arrows represent that the screen is switched with the Screen
shift key.
Use the Parameter setting knob for each parameter selection.
13.5. Audio Output Name Setting
13.5.2. Audio output setting items
O U T 1 – _ _ _ _ _ _ _
Output channel name setting
The flashing portion is the cursor position for entering channel name characters.
Select a character from the alphanumeric character list by rotating the Parameter setting knob, then move the
cursor with the Right shift key.
Entering a new name overwrites the existing name, if there is.
To delete the character, select [ _ ] (under-bar) with the Parameter setting knob. Space cannot be entered.
Up to 7 characters can be used to set the name.
Even when an output channel name has been set, some setting screens display the channel number, not the
set name.
7 characters (default setting: OUT1 – 8) Setting Range
