39
13.3.3. Returning from setting mode to normal use state
• Pressing the Escape/Back key when the setting screen is displayed returns the display to the setting start
screen on the upper hierarchy level.
• Pressing the Memory key at the setting menu screen saves the setting contents and returns the display to
the normal use state.
Normal use state
Setting menu screen
E V E N T 0 1 R O U T E
Setting screen
E V E N T – S E T T I N G
E V E N T 0 1 O U T 1
Setting screen
ESC/BACK
ESC/BACK
MEMORY
[Setting content selection]
Use the Parameter setting knob in most cases.
In some cases, however, use the input and output channel selection keys, or the input and output channel
ON/OFF keys.
For example, to select an input channel, use the input channel selection key as shown below.
I N P U T 1 P R I O R I T Y 1
PARAMETER
I N P U T 1 P R I O R I T Y 8
I N 1 – I N P U T 1 S E L E C T I N P U T C H
1
INPUT SELECT
