41
[1-channel or 2-channel output operation]
UTILITY
ESC/BACK
MEMORY
INPUT SELECT
1 – 8
Normal use state
Setting menu screen
S E L E C T I N P U T C H
Input channel selection
PARAMETER
I N 1 – _ _ _ _ _ _ _
Input channel name setting (p. 42-A1)
Input channel name setting
SS-9001 output zone ON/OFF setting (p. 44-A14)
(For the channel on which the D-001T
is used)
P R E P A G E T O N E – O F F
Pre-paging tone ON/OFF setting
(p. 43-A5)
Operation mode setting (p. 43-A6)
I N 1 – P H A N T O M – O F F
Phantom power ON/OFF setting
(p. 42-A3)
I N 1 – S E N S I T I V I T Y – 1 0
Input sensitivity setting (p. 42-A2)
Trigger setting (p. 44-A11)
(For the channel on which the ZP-001T is used)
M O D E = P A G I N G P O R T
Press for over 2 seconds.
I N 1 Z O N E 1 O F F
I N 1 Z O N E 4 O F F
Priority setting (p. 44-A12)
I N 1 – D U C K E R O F F
Ducker ON/OFF setting (p. 44-A13)
(For the channel on which the AN-001T is not used)
(For the channel on which 900 series module or D-001T is used)
I N 1 P R I O R I T Y 8
I N P U T – S E T T I N G
I N 1 – S E N S I T I V I T Y – 1 0
(For the channel on which the AN-001T is used)
Input sensitivity setting (p. 42-A2)
I N 1 – P H A N T O M – O F F
Phantom power ON/OFF setting (p. 42-A3)
A N C A C T I V E
(When the ANC operation is set
to ACTIVE)
(p. 43-A7)
A N C B Y P A S S
ANC operation ON/OFF setting
(When the ANC operation is set
to BYPASS)
(p. 43-A7)
ANC-activated output setting (p. 43-A8)
M O N I T O R O U T – O F F
Monitor ON/OFF setting (p. 43-A9)
(When Monitor function is ON)
Monitor output channel selection
(p. 43-A10)
M O N I T O R O U T O U T 1
A N C A P P L I E S O U T 1
(For the channel on which the 900
series module is used)
Trigger setting (p. 44-A11)
T R I G G E R = N O N E
T R I G G E R = N O N E
Note
Set the priority level higher than level 8 for
the input channel to be used for broadcast
(e.g. paging using the ZP-001T) that
overrides BGM broadcasts.
