JKSSS+ Series - 77

JKSSS+ Series

2.3 - 4.2KV

MP.5 Event Recorder - 60 Events (Metering Page 5)

The events are listed from oldest to most recent.

Screen 1: Displays the event (i.e. Imbalance Trip) with the

date and time it occurred.

Screen 1a: Displays the current of Phase A, B, C and the

ground fault at the time of the trip.

Screen 1b: Displays the Vab, Vbc, Vca and power factor at the

time of trip.

:
:##/##/## ##:##

IA: ###### IB: ######
IC: ###### G/F: ####

All events will be viewed from oldest event in buffer to most recent event.

2nd
Event

1st
Event

60th
Event

59th
Event

MENU

METERING PAGE 5
Event Recorder (60 event)

Screen 1

Screen 1a

Vab: ###### Vbc: ######
Vca: ###### P/F: ####

Screen 1b

Vab: ###### Vbc: ######
Vca: ###### P/F: ####
