JKSSS+ Series - 70
JKSSS+ Series 2.3 - 4.2KV
6.1 Metering Page List
The following charts list each Metering Page and the functions within that page. The
applicable section of the manual is also referenced.
6.1.1 Metering Menu & Data (Metering Page 1)
Chapter 6 - Metering Pages
The soft starter offers performance metering which gives the user the ability to view
information about the motor and the JKSSS+ unit.
6.1.2 Metering (Metering Page 2)
6 .1.3 RTD Values (Metering Page 3)
Metering
Page
Description of Display Screen
Phase A, B, C and Ground Fault (Option) 1
Average current of the % of imbalance and the motor's RPM 2
Motor load as a percentage of motor FLA 3
Line frequency and present phase sequence 4
Percentage of remaining Thermal Register 5
Thermal capacity required to start the motor 6
Average time required to start 7
Average current during start 8
Measured I 2 T required to start the motor 9
Amount of time required to start the motor during the last successful start 10
Page
1
Metering Menu & Dat
a
Metering
Page
Description of Display Screen
Phase A, B, C currents and Power Factor 1
Phase A, B, C currents and Ground Fault (Option) 2
Displays kW and kVA 3
Displays kVAR and Power Factor 4
Displays Peak ON and kW Demand 5
Displays Peak ON and kVA Demand 6
Displays Peak ON and kVAR Demand 7
Displays Peak ON and Amps Demand 8
Clears Demand values 9
Displays Megawatt hours used 10
Press enter to clear statistics on MWH values 11
Page
2
Meterin
g
Metering
Page
Description of Display Screen
Hottest stator RTD (#1 - 6) 1
Hottest non-stator RTD (#7 - 12) 2
Temperature of start phase A1 in °C and °F 3
Maximum temperature for RTD #1 4
Same as Screens 3 - 4 for RTDs #2 - 12 5 - 26
Clear the maximum temperature register (Level 3 password required) 27
Measured running thermal stabilization time of motor (in minutes) 28
Measured stopped cooling time (to ambient) of motor (in minutes) 29
Page
3
RTD Values
