5.1.6 User I/O Configuration (Setpoint Page 6)
Setpoint
Page
Security
Level
Description
Factory Setting
Default
Range Section
Tachometer Scale Selection Disabled Enabled or Disabled
Manual Tach Scale 4.0 mA: 0 RPM 0 - 3600
Manual Tach Scale 20.0 mA: 2000 RPM 0 - 3600
Tach Accel Trip Mode Select Disabled Underspeed, Overspeed or Disabled
Tach Ramp Time 20 sec 1 - 120
Tach Underspeed Trip PT 1650 RPM 0-3600
Tach Overspeed Trip PT 1850 RPM 0 - 3600
Tach Accel Trip Delay 1 sec 1 - 60
Analog Output #1 RMS Current
Off, RPM 0-3600, Hottest Non-Stator RTD
0-200°C, Hottest Stator RTD
0 - 200°C, RMS Current 0 - 7500 A, %
Motor Load 0 - 600% Kw
Analog Output #1 4mA: 0 0-65535
Analog Output #1 20mA: 250 0-65535
Analog Output #2 % Motor Load Same As Analog Input #1
Analog Output #2 4mA: 0 0-65535
Analog Output #2 20mA: 1000 0-65535
User Programmable External
Inputs
TCB Fault Enabled Enabled or Disabled
Name Ext. Input #1 TCB Fault User Defined, up to 15 Characters
TCB Fault Type NO Normally Open or Closed
TCB Fault Time Delay 1 sec 0-60 sec
External Input #2 Disabled Enabled or Disabled
Name Ext. Input #2 User Defined, up to 15 Characters
External Input #2 Type NO Normally Open or Closed
External Input #2 Time Delay 0 sec 0-60 sec
Dual Ramp Dual Ramp Enabled or Disabled or Dual Ramp
Name Ext. Input #3 Dual Ramp User Defined, up to 15 Characters
Dual Ramp Type NO Normally Open or Closed
Dual Ramp Time Delay 0 sec 0-60 sec
Thermostat Enabled Enabled or Disabled
Name Ext. Input #4 Thermostat User Defined, up to 15 Characters
Thermostat Type NC Normally Open or Closed
Thermostat Time Delay 1 sec 0-60 sec
Page
6
User I/O Configuratio
n
Lavel
2
Passowrd Protectio
n
SP6.4
SP6.5
SP6.1
SP6.3
SP6.2
