JKSSS+ Series - 76
JKSSS+ Series 2.3 - 4.2KV
MP.4 Status (Metering Page 4)
Displays the present status of the soft start.
Screen 1: Displays the present state of the unit as
follows:
Screen 2: Displays the amount of time remaining before
an overload trip will occur.
Screen 3: Displays the amount of time remaining from
a thermal inhibit. The inhibit time comes from
the amount of thermal register remaining
versus the amount of thermal capacity
required to start.
Screen 4: Displays the coast down time remaining
(Backspin time). The time remaining depends
upon the user setting in Setpoint Page 8,
Coast Down Time.
Screen 5: Displays the amount of time remaining before
a start command can be given.
Screen 6: If the number of starts per hour has exceeded
the setting.
(CURRENT STATUS)
O/L TRIP LEFT TO
TRIP: ###### SEC
THERM INH TIME LEFT
: #### MIN
COAST DOWN TIMER
TIME LEFT: #:## MIN
TIME BETWEEN STARTS
TIME: #:## MIN
STARTS PER HOUR TIME
## ## ## ## ## ## ##
MENU
METERING PAGE 4
STATUS
Screen 1 (See note at left)
Screen 2
Screen 3
Screen 4
Screen 5
Screen 6
Screen 1 Note:
CURRENT STATUS Screens include:
1. MOTOR STOPPED
READy TO START
2. MOTOR STARTING
MULT. OF FLA
3. MOTOR RUNNING
AT ###.## x FLA
4. LAST TRIP CAUSE
NONE (or trip cause)
5. PROGRAMMING
SETPOINTS
6. MOTOR STATUS
UNKNOWN STATE ### (displays relay state upon error)
