JKSSS+ Series - 14

JKSSS+ Series

2.3 - 4.2KV

Routine Inspection

Routine scheduled inspection should be established if storage for an extended period is

anticipated. This is to check for condensation, corrosion, vermin, and adequacy of space

heating. Prior to inspection, the equipment should be carefully examined for evidence of

physical damage, corrosion, or other deterioration.

Do not install equipment found to have damage or

deterioration that could affect the unit performance.

Overhead should be checked for plumbing condensation, sprinklers or similar possible

sources of trouble. A clearance of 1/2 inch should be provided between a wall and the rear

of the controller for indoor equipment, when rear access is not required. If rear access is

required in either environment, a minimum of 30 inches should be provided. A minimum

of 48 inches working space should be allowed in front of the controller. This minimum

should be increased if necessary to accommodate movement around open enclosure

doors to comply with applicable codes.

SERVICE CONDITIONS

Toshiba medium voltage controllers are intended for usual service conditions as defined

by NEMA. The equipment should not be exposed to corrosive or explosive fumes, dusts,

vapors, dripping or standing water, abnormal vibration, shock, tilting, or other abnormal

operation conditions. The temperature of the ambient air surrounding the controller should

be between the limits of 0°C(32°F) and +40°C(104°F). The altitude of the equipment
installed should not exceed 3300 ft (1000m).

NOTE: Temperature or altitude conditions outside of the usual limits may require derating

or other special equipment, such as heating, cooling or ventilation. Contact Toshiba for

further information.

If the location for installation is damp, space heaters may be required. If space heaters

are furnished inside the controller, they should be connected in accordance with the wir-
ing diagram furnished.

Do not install this equipment in areas where unusual service

conditions exist, unless the equipment has been specially

designed for the particular environment.

Installation Site Preparation

It is recommended that site preparation be completed before the controller is unpacked,

so that possible problems such as headroom, conduit location, cable tray locations, ven-

tilation, etc. can be solved, assuring a proper installation in compliance with the building

plans and codes. The floor on which the controller will be placed must be level so that the

enclosure is not distorted when bolted in place. Ensure the equipment adequately clears

any underground raceways or cables.

WARNING

WARNING
