Appendix E
APPENDIX E
Method for Making the Cable for Connection to the PC/Host
Explained below is the method for making the cable that connects the NT600S and the PC/Host.
Connect the wires to the connectors in accordance with the connector specification for each unit.
Making the Cable for Connection to the PC
Parts Required
Two connectors, two connector covers and one cable are required to make up a connecting cable. One connector
and one connector cover is supplied with most PCs.
Name Model Delivered with Remarks
Connector XM2A-0901 C series CQM1, C200HS,
C200HX/HG/HE
CVM1/CV series CPU unit
CV500-LK201 9-pin, manufactured by OMRON
XM2A-2501 C500-LK203
C500-LK201
C200H-LK201 25-pin, manufactured by OMRON
DB-25P C500-LK201-V1
C120-LK201-V1 25-pin, manufactured by JAE
Connector
Cover XM2S-0911 C series CQM1, C200HS,
C200HX/HG/HE
CVM1/CV series CPU unit
CV500-LK201 9-pin, manufactured by OMRON
XM2S-2511 C500-LK203
C500-LK201
C200H-LK201 25-pin, manufactured by OMRON
DB-C2-J9 C500-LK201-V1
C120-LK201-V1 25-pin, manufactured by JAE
When connecting the NT600S to an OMRON PLC C H , the connector and the
connector hood must be prepared separately since they are not supplied with the
C
H.
The connector provided in the CPU unit of the C H is a 9-pin connector. For the
connection, the following connector and connector hood should be prepared.
Connector: XM2A-0901 (9-pin type, OMRON)
Connector hood: XM2S-0911 (9-pin type, OMRON)
Prepare the cable recommended by OMRON.
The recommended cables are indicated in the following table.
Name Type Remark
Cable
AWG28 5P
IFVV-SB
Multiconductor shielded cable (FUJIKURA, Ltd.)
Cable
CO-MA-VV-SB
5P
28AWG
Multiconductor shielded cable (HITACHI Cable, Ltd.)
