Reference
Section 6-4
Specifying the Character-string
The character-string to be displayed can be specified by the following command.
Specify Displayed Characters
Format
1B
[ESC]
34
4 n
1
n
2
c
1
c
2
c
n
c
3
n
1
n
2
: Character string length as a number of normal characters (2-digit hexadeci-
mal)
01 to 50H (1 to 80)
c
1
c
2
c
3
to c
n
: Character-string to display
Description The character string is displayed from the cursor position.
The character-string data can contain a mixture of normal (alphanumeric) char-
acters and marks. Refer to
Appendix M Special Characters for details.
The character string is displayed according to the enlargement and display at-
tributes set with commands.
The character string continues on the next line if it cannot fit into a single line.
Set the position where the character string is displayed with the Set Cursor Posi-
tion Command (refer to
7-4-2 Set Cursor Position).
7-4-3 Displaying Figures
Displaying the Line
Use the following command to display a polyline.
Draw Polyline
Format
1B
[ESC]
37
7 m
1
m
2
x0
1
x0
2
x0
3
y0
1
y0
2
y0
3
xn
1
xn
2
xn
3
yn
1
yn
2
yn
3
m
1
, m
2
: Number of lines to draw (2-digit hexadecimal)
01 to 28
H
(1 to 40)
x0
1
x0
2
x0
3
to xn
1
xn
2
xn
3
:X coordinates of line end points (3-digit BCD)
y0
1
y0
2
y0
3
to yn
1
yn
2
yn
3
:Y coordinates of line end points (3-digit BCD)
X coordinate Y coordinate
000 to 639 000 to 399
Description Draws the specified number of lines between the specified points.
