Omron NT-series Programmable Terminal V022-E3-1 User Manual

Page 120

background image

[ SYSTEM MENU ]

Quit

Transmit Mode

Maintenance Mode

[ MAINTENANCE MENU ]

Quit

PT Setting Status

I/O Check

Display History

Memory Init.

Memory Switches

[ I/O CHECK MENU ]

Quit

LED

Buzzer

Backlight

Touch Switch

LCD Display

Communication I/F

DIP-Switch

[ COMMUNICATION I/F CHECK MENU ]

Quit

Tool Transmit

RS-232C Transmit

.

Section 3-9

Select “Maintenance Mode”.

Select “I/O Check”.

Select “Communication I/F”.

Select

“Tool

Transmit”

or

“RS-232C Transmit”.

(Select “Tool Transmit”)
