Runco LS-10d Installation/Operation Manual

PRE

IMINAR

• PROJECTION LENS

If needed, a light shield accessory is provided with the lens to minimize stray light
emissions. (Use it only when the vertical offset is 50% of the screen height or greater.)
The light shield attaches to the end of the lens.

Figure 2-2. LS-10d Rear/Bottom/Top View

Runco Logo
Badge

Lamp Module
Cover

Ceiling Mount
Holes

Rear Cover

Cable

Opening

Adjustable

Feet
