Package Dimensions

2.0 ± 0.2

0.3

2.1 ± 0.3

0.65 0.6

1.25 ± 0.2

0.16

0 – 0.1

0.9 ± 0.1

+ 0.1

– 0.05

0.4

+ 0.1

– 0.05

0.3

+ 0.1

– 0.05

+ 0.1

– 0.06

0.65 0.65

1.3 ± 0.2

0.3

+ 0.1

– 0.05

0.425

0.2

Package Code
JEDEC
JEITA
Mass (reference value)

CMPAK-4(T)
—
Conforms
0.006 g

1.25 ± 0.1

As of January, 2003

Unit: mm

Ordering Information

Part Name

Quantity

Shipping Container

HSG1001VD-

3000 pcs

178 mm Taping Reel

Note:

For some grades, production may be terminated. Please contact the Renesas sales office to check the state of
production before ordering the product.
