Renesas HSG1001 - Manual (Page 15)

HSG1001
Rev.1.00, Apr.08.2004, page 15 of 37
S Parameter
(V
CE
= 1 V, I
C
= 7 mA, Z
O
= 50
Ω
)
S11 S21 S12 S22
f (MHz) MAG ANG MAG ANG MAG ANG MAG ANG
100 0.901 -8.2 19.13 172.0 0.0032 20.3 0.977 -5.2
200 0.879 -15.9 18.87 164.7 0.0102 82.9 0.975 -9.9
300 0.852 -23.3 18.38 157.9 0.0143 69.5 0.950 -14.5
400 0.827 -30.5 17.86 151.6 0.0206 75.7 0.922 -18.7
500 0.792 -37.9 17.31 145.7 0.0229 69.9 0.889 -22.9
600 0.755 -44.8 16.68 140.1 0.0277 64.0 0.852 -26.3
700 0.719 -51.1 15.91 135.0 0.0305 62.1 0.815 -29.7
800 0.682 -57.4 15.24 130.0 0.0332 58.3 0.779 -32.6
900 0.645 -63.9 14.67 125.5 0.0349 56.8 0.742 -35.0
1000 0.608 -69.5 13.98 121.0 0.0387 54.2 0.709 -37.5
1100 0.575 -75.2 13.31 116.9 0.0404 52.3 0.678 -39.4
1200 0.541 -80.8 12.73 112.9 0.0419 51.1 0.648 -41.2
1300 0.511 -85.8 12.11 109.4 0.0441 50.2 0.620 -43.0
1400 0.485 -90.9 11.54 106.1 0.0458 49.9 0.595 -44.4
1500 0.459 -96.1 11.03 102.9 0.0478 48.1 0.572 -45.9
1600 0.436 -101.2 10.54 99.8 0.0486 47.2 0.550 -47.1
1700 0.415 -106.0 10.08 97.0 0.0506 46.5 0.530 -48.4
1800 0.398 -110.8 9.65 94.3 0.0526 45.6 0.510 -49.5
1900 0.381 -115.7 9.25 91.7 0.0538 45.4 0.492 -50.7
2000 0.367 -120.6 8.88 89.2 0.0550 44.7 0.475 -51.8
2200 0.343 -130.0 8.21 84.5 0.0577 43.6 0.446 -53.8
2400 0.326 -139.3 7.62 80.1 0.0601 42.6 0.419 -55.9
2600 0.314 -148.3 7.10 75.9 0.0631 41.5 0.395 -58.0
2800 0.306 -157.2 6.64 72.0 0.0661 40.6 0.374 -60.0
3000 0.302 -165.2 6.23 68.2 0.0695 40.1 0.355 -61.9
3200 0.301 -173.1 5.87 64.5 0.0713 39.8 0.336 -64.1
3400 0.302 179.5 5.54 61.0 0.0747 38.7 0.320 -66.4
3600 0.304 172.8 5.23 57.6 0.0780 37.8 0.304 -68.2
3800 0.308 166.9 4.97 54.5 0.0803 37.4 0.292 -70.3
4000 0.315 161.4 4.73 51.2 0.0830 36.0 0.281 -72.8
4200 0.323 156.2 4.51 48.1 0.0869 35.3 0.269 -75.4
4400 0.331 151.4 4.31 44.9 0.0899 34.1 0.258 -78.1
4600 0.339 146.9 4.13 41.9 0.0932 32.8 0.247 -80.6
4800 0.347 142.6 3.96 38.9 0.0965 31.7 0.237 -83.4
5000 0.355 138.5 3.81 35.9 0.0998 30.4 0.227 -86.1
5200 0.364 134.6 3.66 32.9 0.1029 29.2 0.218 -89.1
5400 0.372 131.1 3.53 29.9 0.1060 27.8 0.208 -91.9
5600 0.380 127.6 3.40 27.0 0.1094 26.2 0.199 -95.1
5800 0.389 124.3 3.29 24.1 0.1121 24.8 0.190 -98.4
6000 0.398 121.0 3.18 21.2 0.1154 23.8 0.181 -101.3
