HSG1001
Rev.1.00, Apr.08.2004, page 26 of 37
S Parameter
(V
CE
= 3 V, I
C
= 1 mA, Z
O
= 50
Ω
)
S11 S21 S12 S22
f (MHz) MAG ANG MAG ANG MAG ANG MAG ANG
100 0.985 -3.4 3.17 176.7 0.0066 141.1 0.992 -2.0
200 0.984 -6.7 3.18 173.2 0.0078 80.2 0.998 -3.6
300 0.976 -9.8 3.17 170.1 0.0157 85.7 0.994 -5.5
400 0.977 -13.5 3.18 167.3 0.0172 82.3 0.989 -7.2
500 0.972 -17.0 3.19 164.4 0.0216 74.9 0.985 -9.1
600 0.967 -20.2 3.19 161.6 0.0260 74.7 0.980 -10.8
700 0.962 -23.7 3.16 158.6 0.0313 73.3 0.973 -12.6
800 0.955 -27.0 3.14 155.6 0.0349 70.8 0.966 -14.3
900 0.949 -30.7 3.17 153.7 0.0385 69.3 0.958 -16.0
1000 0.941 -34.2 3.16 150.1 0.0430 65.7 0.951 -17.6
1100 0.931 -37.6 3.16 147.3 0.0471 63.7 0.942 -19.3
1200 0.922 -41.2 3.16 143.8 0.0508 61.6 0.933 -20.9
1300 0.912 -44.7 3.13 141.0 0.0546 59.5 0.924 -22.6
1400 0.903 -48.2 3.11 138.3 0.0581 57.7 0.914 -24.2
1500 0.891 -51.9 3.10 135.4 0.0615 55.2 0.903 -25.9
1600 0.878 -55.7 3.11 132.4 0.0646 53.1 0.893 -27.4
1700 0.868 -59.3 3.08 129.6 0.0674 50.5 0.882 -29.0
1800 0.856 -63.0 3.04 126.7 0.0705 48.5 0.871 -30.5
1900 0.845 -66.7 3.02 124.0 0.0727 46.7 0.861 -32.1
2000 0.832 -70.7 3.01 121.2 0.0752 43.9 0.849 -33.6
2200 0.807 -78.2 2.95 115.5 0.0800 39.7 0.827 -36.7
2400 0.782 -86.0 2.90 110.0 0.0836 35.9 0.802 -39.6
2600 0.758 -93.8 2.84 104.6 0.0868 32.1 0.778 -42.5
2800 0.734 -101.8 2.78 99.2 0.0897 28.7 0.756 -45.2
3000 0.710 -109.7 2.72 93.7 0.0910 25.0 0.734 -47.8
3200 0.690 -117.5 2.64 88.6 0.0921 21.7 0.713 -50.6
3400 0.671 -125.3 2.57 83.5 0.0919 18.5 0.694 -53.2
3600 0.654 -132.9 2.49 78.6 0.0926 15.4 0.673 -55.7
3800 0.639 -140.3 2.41 73.9 0.0911 12.9 0.656 -58.2
4000 0.629 -147.6 2.34 69.2 0.0900 10.7 0.641 -60.6
4200 0.620 -154.9 2.28 64.7 0.0892 8.8 0.625 -63.1
4400 0.613 -161.8 2.20 60.2 0.0881 7.2 0.612 -65.6
4600 0.606 -168.6 2.14 55.9 0.0867 5.8 0.600 -68.0
4800 0.602 -175.1 2.07 51.7 0.0850 3.8 0.587 -70.4
5000 0.600 178.6 2.01 47.6 0.0837 3.4 0.576 -72.8
5200 0.599 172.5 1.95 43.5 0.0820 2.5 0.564 -75.4
5400 0.599 166.8 1.88 39.7 0.0805 2.5 0.554 -77.9
5600 0.599 161.3 1.83 35.9 0.0795 2.3 0.545 -80.3
5800 0.600 155.9 1.78 32.1 0.0785 2.5 0.536 -83.0
6000 0.602 150.7 1.72 28.4 0.0776 3.2 0.527 -85.5
