HSG1001
Rev.1.00, Apr.08.2004, page 16 of 37
S Parameter
(V
CE
= 1 V, I
C
= 10 mA, Z
O
= 50
Ω
)
S11 S21 S12 S22
f (MHz) MAG ANG MAG ANG MAG ANG MAG ANG
100 0.852 -10.4 25.12 170.4 0.0070 154.3 0.965 -7.3
200 0.832 -19.6 24.69 161.6 0.0119 85.7 0.958 -12.0
300 0.796 -28.4 23.83 153.6 0.0132 77.5 0.924 -17.3
400 0.756 -37.2 22.85 146.3 0.0173 72.5 0.881 -22.1
500 0.710 -45.4 21.78 139.6 0.0232 64.5 0.837 -26.6
600 0.665 -53.3 20.63 133.4 0.0251 63.4 0.792 -30.1
700 0.622 -60.3 19.37 127.9 0.0278 59.8 0.747 -33.2
800 0.577 -67.1 18.24 122.7 0.0303 58.1 0.705 -35.8
900 0.536 -73.7 17.23 118.1 0.0332 55.7 0.668 -38.0
1000 0.501 -79.7 16.18 113.8 0.0352 53.6 0.632 -39.9
1100 0.467 -85.5 15.22 109.9 0.0365 54.2 0.601 -41.5
1200 0.436 -91.3 14.37 106.2 0.0387 51.7 0.572 -42.9
1300 0.409 -96.2 13.55 102.9 0.0397 52.0 0.546 -44.3
1400 0.385 -101.8 12.81 99.8 0.0418 51.5 0.523 -45.4
1500 0.364 -107.1 12.15 96.9 0.0429 50.7 0.500 -46.5
1600 0.345 -112.4 11.53 94.2 0.0447 50.2 0.482 -47.3
1700 0.329 -117.3 10.96 91.6 0.0462 50.0 0.464 -48.4
1800 0.315 -122.4 10.45 89.2 0.0476 49.5 0.447 -49.4
1900 0.303 -127.3 9.97 86.8 0.0498 49.7 0.433 -50.2
2000 0.292 -132.5 9.54 84.6 0.0509 49.0 0.417 -51.0
2200 0.277 -142.2 8.76 80.3 0.0541 48.3 0.392 -52.8
2400 0.267 -151.7 8.10 76.2 0.0574 48.4 0.369 -54.6
2600 0.262 -160.7 7.52 72.5 0.0611 46.9 0.348 -56.4
2800 0.261 -169.2 7.02 68.8 0.0646 46.7 0.331 -58.3
3000 0.263 -177.0 6.57 65.3 0.0673 44.9 0.314 -60.2
3200 0.267 175.6 6.17 61.9 0.0710 44.9 0.297 -62.6
3400 0.272 168.9 5.82 58.6 0.0744 43.4 0.282 -64.8
3600 0.277 162.8 5.49 55.5 0.0772 42.7 0.269 -66.8
3800 0.283 157.6 5.21 52.5 0.0807 41.4 0.258 -69.0
4000 0.292 152.8 4.96 49.5 0.0839 40.3 0.247 -71.6
4200 0.301 148.2 4.73 46.5 0.0883 39.1 0.236 -74.3
4400 0.309 144.1 4.52 43.5 0.0907 37.7 0.226 -77.0
4600 0.319 140.0 4.33 40.6 0.0949 36.6 0.217 -79.7
4800 0.328 136.2 4.15 37.7 0.0984 35.2 0.207 -82.5
5000 0.337 132.5 3.98 34.8 0.1019 33.7 0.198 -85.5
5200 0.348 129.2 3.83 31.9 0.1056 31.6 0.187 -88.8
5400 0.355 126.1 3.69 29.1 0.1092 30.5 0.179 -92.1
5600 0.364 122.9 3.56 26.3 0.1124 28.9 0.171 -95.2
5800 0.373 119.8 3.43 23.5 0.1155 27.3 0.162 -98.6
6000 0.382 117.0 3.32 20.6 0.1187 25.8 0.153 -102.4
