HSG1001
Rev.1.00, Apr.08.2004, page 30 of 37
S Parameter
(V
CE
= 3 V, I
C
= 10 mA, Z
O
= 50
Ω
)
S11 S21 S12 S22
f (MHz) MAG ANG MAG ANG MAG ANG MAG ANG
100 0.869 -9.2 25.72 170.8 0.0029 161.5 0.979 -6.0
200 0.847 -17.6 25.14 162.6 0.0068 89.6 0.971 -9.8
300 0.814 -25.7 24.24 155.0 0.0133 71.1 0.942 -14.3
400 0.778 -33.9 23.28 148.1 0.0152 73.5 0.906 -18.2
500 0.732 -41.5 22.26 141.5 0.0180 67.2 0.870 -21.9
600 0.686 -48.8 21.13 135.5 0.0209 64.6 0.830 -24.9
700 0.645 -55.3 19.92 130.1 0.0231 63.0 0.791 -27.6
800 0.601 -61.5 18.82 125.0 0.0250 59.1 0.755 -29.8
900 0.558 -67.8 17.81 120.4 0.0271 57.3 0.723 -31.6
1000 0.520 -73.2 16.80 116.1 0.0295 57.6 0.691 -33.2
1100 0.486 -78.5 15.83 112.2 0.0308 56.0 0.663 -34.6
1200 0.452 -83.8 14.98 108.5 0.0319 54.4 0.637 -35.8
1300 0.422 -88.7 14.14 105.1 0.0339 54.4 0.614 -36.9
1400 0.397 -93.6 13.40 102.0 0.0350 55.5 0.592 -37.9
1500 0.373 -98.4 12.72 99.1 0.0366 54.1 0.574 -38.9
1600 0.351 -103.3 12.09 96.3 0.0382 53.1 0.555 -39.5
1700 0.332 -107.9 11.51 93.7 0.0397 52.1 0.540 -40.4
1800 0.315 -112.8 10.98 91.2 0.0401 52.0 0.524 -41.1
1900 0.300 -117.5 10.49 88.9 0.0419 51.5 0.510 -41.9
2000 0.287 -122.3 10.04 86.6 0.0435 52.4 0.497 -42.7
2200 0.266 -131.7 9.24 82.3 0.0464 51.1 0.474 -44.2
2400 0.251 -141.4 8.55 78.3 0.0490 51.3 0.453 -45.8
2600 0.241 -150.6 7.95 74.5 0.0520 50.4 0.433 -47.3
2800 0.235 -159.8 7.42 70.9 0.0554 49.7 0.418 -48.9
3000 0.233 -168.4 6.96 67.4 0.0580 49.0 0.401 -50.5
3200 0.235 -176.3 6.54 64.0 0.0613 47.8 0.388 -52.6
3400 0.238 176.0 6.18 60.7 0.0641 47.2 0.374 -54.3
3600 0.241 169.1 5.84 57.6 0.0668 46.7 0.361 -55.9
3800 0.246 163.4 5.54 54.6 0.0705 46.2 0.350 -57.8
4000 0.255 158.2 5.28 51.6 0.0737 45.0 0.341 -60.0
4200 0.261 153.0 5.03 48.6 0.0770 43.8 0.331 -62.4
4400 0.270 148.1 4.81 45.7 0.0806 42.6 0.321 -64.5
4600 0.279 144.0 4.61 42.8 0.0838 41.7 0.313 -66.9
4800 0.288 139.9 4.42 40.0 0.0860 40.5 0.303 -69.1
5000 0.297 136.1 4.25 37.1 0.0901 39.0 0.294 -71.6
5200 0.306 132.5 4.10 34.3 0.0929 37.6 0.286 -74.0
5400 0.314 129.0 3.95 31.5 0.0967 36.4 0.276 -76.4
5600 0.323 125.8 3.81 28.7 0.0999 34.5 0.269 -78.8
5800 0.331 122.7 3.68 25.9 0.1027 33.1 0.260 -81.4
6000 0.340 119.6 3.56 23.1 0.1058 31.5 0.252 -83.8
