HSG1001
Rev.1.00, Apr.08.2004, page 18 of 37
S Parameter
(V
CE
= 1 V, I
C
= 30 mA, Z
O
= 50
Ω
)
S11 S21 S12 S22
f (MHz) MAG ANG MAG ANG MAG ANG MAG ANG
100 0.531 -28.6 36.92 162.7 0.0057 61.8 0.641 -10.4
200 0.487 -55.2 33.95 146.9 0.0102 52.5 0.624 -21.6
300 0.440 -77.9 29.87 134.0 0.0146 57.5 0.549 -27.4
400 0.412 -97.6 25.87 123.9 0.0164 54.1 0.488 -31.1
500 0.392 -114.0 22.27 115.8 0.0200 52.6 0.441 -33.5
600 0.384 -127.3 19.28 109.5 0.0221 53.2 0.403 -34.7
700 0.379 -137.7 16.92 104.6 0.0236 53.7 0.372 -35.2
800 0.379 -146.9 14.95 100.1 0.0256 53.5 0.350 -35.4
900 0.380 -154.2 13.40 96.3 0.0270 55.7 0.332 -35.7
1000 0.382 -160.7 12.13 93.1 0.0297 53.8 0.315 -36.0
1100 0.384 -166.2 11.06 90.0 0.0316 55.0 0.300 -36.1
1200 0.388 -171.5 10.12 87.3 0.0333 53.8 0.289 -36.2
1300 0.392 -175.8 9.34 84.8 0.0352 55.5 0.279 -36.5
1400 0.395 -179.8 8.70 82.5 0.0376 56.1 0.270 -36.8
1500 0.399 176.4 8.12 80.2 0.0391 55.6 0.260 -37.2
1600 0.403 172.9 7.60 78.0 0.0417 56.1 0.252 -37.4
1700 0.407 169.8 7.15 76.0 0.0437 55.4 0.244 -37.9
1800 0.412 166.8 6.76 74.0 0.0449 55.3 0.237 -38.5
1900 0.415 163.9 6.40 72.1 0.0478 55.3 0.230 -39.0
2000 0.421 161.3 6.07 70.2 0.0498 55.0 0.223 -39.8
2200 0.429 156.2 5.52 66.6 0.0537 54.4 0.211 -41.2
2400 0.439 151.7 5.05 63.2 0.0581 53.6 0.199 -42.8
2600 0.448 147.5 4.65 59.8 0.0629 52.4 0.187 -44.7
2800 0.459 143.7 4.32 56.6 0.0665 52.0 0.175 -46.7
3000 0.467 140.0 4.02 53.4 0.0706 49.5 0.165 -48.9
3200 0.477 136.5 3.76 50.3 0.0756 48.5 0.154 -51.3
3400 0.485 133.2 3.53 47.2 0.0794 47.3 0.144 -53.8
3600 0.492 130.0 3.32 44.3 0.0830 46.0 0.133 -55.7
3800 0.500 127.2 3.14 41.4 0.0872 45.1 0.125 -59.0
4000 0.510 124.3 2.98 38.5 0.0923 43.0 0.116 -62.4
4200 0.517 121.6 2.83 35.6 0.0954 41.3 0.108 -66.1
4400 0.525 119.0 2.70 32.7 0.0999 39.7 0.100 -69.9
4600 0.533 116.3 2.58 29.9 0.1036 38.3 0.091 -73.7
4800 0.539 113.7 2.47 27.1 0.1071 36.3 0.083 -78.1
5000 0.546 111.2 2.37 24.2 0.1109 35.2 0.075 -82.6
5200 0.554 108.7 2.27 21.4 0.1150 32.7 0.067 -87.9
5400 0.559 106.2 2.18 18.6 0.1188 30.9 0.059 -93.5
5600 0.566 103.8 2.10 15.9 0.1226 29.4 0.051 -100.4
5800 0.571 101.4 2.03 13.1 0.1266 27.5 0.044 -108.6
6000 0.578 99.0 1.95 10.3 0.1300 25.4 0.037 -119.6
