HSG1001
Rev.1.00, Apr.08.2004, page 19 of 37
S Parameter
(V
CE
= 2 V, I
C
= 1 mA, Z
O
= 50
Ω
)
S11 S21 S12 S22
f (MHz) MAG ANG MAG ANG MAG ANG MAG ANG
100 0.987 -3.3 3.18 176.7 0.0025 47.3 0.995 -1.9
200 0.979 -6.9 3.18 173.1 0.0083 94.0 0.997 -3.8
300 0.976 -9.9 3.18 170.0 0.0132 83.2 0.994 -5.8
400 0.973 -13.7 3.18 167.2 0.0190 80.7 0.989 -7.6
500 0.969 -17.1 3.19 164.2 0.0238 81.3 0.984 -9.4
600 0.965 -20.5 3.19 161.4 0.0287 76.5 0.977 -11.2
700 0.958 -23.9 3.15 158.4 0.0328 72.7 0.971 -13.0
800 0.952 -27.3 3.14 155.3 0.0372 70.5 0.964 -14.8
900 0.947 -30.9 3.17 153.3 0.0411 68.4 0.956 -16.5
1000 0.938 -34.4 3.16 149.8 0.0453 65.8 0.946 -18.2
1100 0.929 -38.0 3.15 146.9 0.0492 63.8 0.938 -19.9
1200 0.919 -41.6 3.16 143.5 0.0527 60.2 0.928 -21.6
1300 0.909 -45.1 3.12 140.6 0.0569 58.8 0.918 -23.4
1400 0.900 -48.7 3.10 137.9 0.0614 56.7 0.909 -25.0
1500 0.888 -52.4 3.09 135.0 0.0650 54.8 0.898 -26.7
1600 0.876 -56.2 3.10 132.0 0.0670 51.9 0.886 -28.1
1700 0.865 -59.8 3.07 129.2 0.0705 50.0 0.876 -29.8
1800 0.854 -63.5 3.03 126.3 0.0742 47.3 0.864 -31.4
1900 0.841 -67.2 3.01 123.5 0.0767 45.8 0.853 -33.0
2000 0.829 -71.2 3.00 120.8 0.0795 43.7 0.841 -34.7
2200 0.805 -78.8 2.93 115.1 0.0840 39.4 0.819 -37.7
2400 0.781 -86.6 2.88 109.5 0.0885 35.5 0.793 -40.7
2600 0.755 -94.5 2.82 104.1 0.0915 31.9 0.769 -43.6
2800 0.733 -102.5 2.76 98.7 0.0940 27.6 0.746 -46.4
3000 0.708 -110.4 2.70 93.2 0.0960 23.6 0.725 -49.1
3200 0.689 -118.3 2.62 88.0 0.0964 20.7 0.702 -52.0
3400 0.670 -126.1 2.55 82.9 0.0981 17.6 0.681 -54.6
3600 0.653 -133.7 2.47 78.0 0.0964 14.2 0.661 -57.1
3800 0.639 -141.0 2.39 73.3 0.0958 12.1 0.643 -59.7
4000 0.629 -148.4 2.32 68.6 0.0960 9.8 0.627 -62.3
4200 0.619 -155.7 2.26 64.1 0.0946 7.5 0.612 -64.7
4400 0.612 -162.5 2.18 59.7 0.0935 5.7 0.597 -67.4
4600 0.607 -169.3 2.12 55.3 0.0919 4.3 0.584 -69.7
4800 0.603 -175.8 2.05 51.1 0.0906 2.9 0.572 -72.2
5000 0.600 178.0 1.99 47.0 0.0881 2.0 0.560 -74.7
5200 0.599 171.8 1.93 42.9 0.0876 1.0 0.549 -77.2
5400 0.600 166.2 1.87 39.1 0.0857 0.3 0.539 -79.8
5600 0.601 160.7 1.81 35.2 0.0842 0.5 0.529 -82.3
5800 0.601 155.3 1.76 31.3 0.0827 -0.2 0.519 -84.9
6000 0.603 150.1 1.71 27.7 0.0823 0.7 0.509 -87.6
