Renesas HSG1001 - Manual (Page 21)

HSG1001
Rev.1.00, Apr.08.2004, page 21 of 37
S Parameter
(V
CE
= 2 V, I
C
= 5 mA, Z
O
= 50
Ω
)
S11 S21 S12 S22
f (MHz) MAG ANG MAG ANG MAG ANG MAG ANG
100 0.923 -6.2 14.39 173.5 0.0092 34.3 0.979 -3.2
200 0.915 -12.3 14.26 167.6 0.0094 83.2 0.987 -7.1
300 0.896 -18.2 14.03 162.0 0.0144 73.0 0.974 -10.7
400 0.878 -24.5 13.78 156.6 0.0167 76.6 0.956 -14.0
500 0.855 -30.4 13.53 151.5 0.0207 68.8 0.935 -17.2
600 0.828 -36.3 13.22 146.7 0.0254 70.2 0.912 -20.1
700 0.803 -41.8 12.78 142.1 0.0285 65.0 0.887 -23.0
800 0.774 -47.2 12.41 137.6 0.0310 61.7 0.860 -25.6
900 0.743 -52.9 12.15 133.5 0.0340 60.5 0.833 -27.9
1000 0.712 -58.1 11.75 129.1 0.0364 58.8 0.806 -30.1
1100 0.682 -63.2 11.35 125.1 0.0403 56.0 0.781 -32.1
1200 0.650 -68.4 11.01 121.1 0.0400 53.8 0.754 -34.0
1300 0.621 -73.1 10.60 117.5 0.0421 51.7 0.729 -35.8
1400 0.594 -78.0 10.21 114.1 0.0452 50.4 0.707 -37.4
1500 0.566 -82.8 9.87 110.7 0.0464 48.2 0.684 -38.9
1600 0.540 -87.5 9.53 107.4 0.0478 47.9 0.663 -40.2
1700 0.517 -92.1 9.18 104.4 0.0498 46.6 0.644 -41.6
1800 0.495 -96.7 8.85 101.5 0.0508 45.0 0.624 -42.8
1900 0.475 -101.1 8.54 98.7 0.0516 44.5 0.606 -44.1
2000 0.455 -105.8 8.25 96.0 0.0528 43.6 0.589 -45.1
2200 0.423 -114.6 7.69 90.9 0.0556 41.7 0.558 -47.3
2400 0.395 -123.6 7.21 86.0 0.0569 41.1 0.530 -49.3
2600 0.373 -132.2 6.76 81.5 0.0599 38.9 0.504 -51.4
2800 0.357 -141.1 6.36 77.2 0.0616 39.1 0.482 -53.3
3000 0.345 -149.5 5.99 73.1 0.0633 38.3 0.461 -55.1
3200 0.338 -157.6 5.66 69.1 0.0662 37.4 0.443 -57.2
3400 0.332 -165.6 5.36 65.3 0.0680 36.9 0.425 -59.2
3600 0.328 -172.7 5.08 61.7 0.0695 35.7 0.409 -61.0
3800 0.327 -179.6 4.83 58.3 0.0719 35.8 0.396 -62.9
4000 0.330 174.2 4.61 54.9 0.0743 35.2 0.384 -65.0
4200 0.335 168.2 4.40 51.5 0.0772 34.1 0.372 -67.3
4400 0.340 162.6 4.22 48.2 0.0795 33.9 0.361 -69.5
4600 0.346 157.3 4.04 45.0 0.0817 32.9 0.351 -71.7
4800 0.352 152.4 3.88 41.9 0.0849 31.9 0.341 -73.9
5000 0.359 147.7 3.73 38.7 0.0868 31.3 0.331 -76.2
5200 0.366 143.2 3.60 35.6 0.0894 30.5 0.321 -78.6
5400 0.374 139.0 3.46 32.6 0.0931 29.4 0.312 -81.1
5600 0.381 135.1 3.35 29.6 0.0949 28.6 0.304 -83.5
5800 0.388 131.3 3.23 26.6 0.0978 27.0 0.294 -86.0
6000 0.396 127.5 3.13 23.6 0.1013 26.2 0.285 -88.5
