HSG1001
Rev.1.00, Apr.08.2004, page 23 of 37
S Parameter
(V
CE
= 2 V, I
C
= 10 mA, Z
O
= 50
Ω
)
S11 S21 S12 S22
f (MHz) MAG ANG MAG ANG MAG ANG MAG ANG
100 0.864 -9.4 25.72 170.8 0.0082 99.3 0.968 -5.9
200 0.840 -18.0 25.13 162.4 0.0078 94.0 0.967 -10.4
300 0.804 -26.3 24.22 154.7 0.0121 80.8 0.937 -15.0
400 0.769 -34.7 23.24 147.6 0.0174 71.6 0.902 -19.2
500 0.725 -42.4 22.19 141.1 0.0196 68.5 0.863 -23.1
600 0.679 -49.7 21.06 135.0 0.0214 64.0 0.822 -26.1
700 0.636 -56.4 19.83 129.6 0.0247 62.5 0.782 -29.0
800 0.592 -62.7 18.72 124.4 0.0269 59.2 0.744 -31.2
900 0.551 -69.0 17.70 119.9 0.0270 58.5 0.707 -33.0
1000 0.514 -74.6 16.67 115.6 0.0296 55.8 0.678 -34.9
1100 0.478 -80.1 15.71 111.6 0.0319 54.7 0.649 -36.3
1200 0.446 -85.5 14.85 107.9 0.0334 54.7 0.622 -37.5
1300 0.417 -90.3 14.02 104.6 0.0348 54.6 0.597 -38.6
1400 0.392 -95.3 13.27 101.5 0.0368 54.4 0.577 -39.6
1500 0.367 -100.3 12.60 98.6 0.0378 53.4 0.556 -40.6
1600 0.347 -105.1 11.97 95.8 0.0390 53.4 0.538 -41.4
1700 0.329 -110.0 11.39 93.2 0.0414 52.8 0.521 -42.3
1800 0.313 -114.8 10.87 90.7 0.0428 52.3 0.505 -43.0
1900 0.299 -119.8 10.38 88.4 0.0440 52.2 0.491 -43.9
2000 0.286 -124.6 9.93 86.1 0.0444 51.2 0.477 -44.6
2200 0.267 -134.2 9.14 81.8 0.0486 51.2 0.454 -46.1
2400 0.254 -143.7 8.45 77.8 0.0512 50.7 0.432 -47.7
2600 0.244 -153.0 7.85 74.0 0.0541 49.6 0.412 -49.3
2800 0.240 -162.2 7.33 70.4 0.0579 48.6 0.395 -51.0
3000 0.239 -170.3 6.87 66.9 0.0611 48.2 0.380 -52.8
3200 0.241 -178.5 6.46 63.5 0.0630 47.2 0.365 -54.8
3400 0.244 174.3 6.10 60.2 0.0659 46.9 0.351 -56.6
3600 0.249 167.5 5.76 57.1 0.0687 46.0 0.337 -58.3
3800 0.254 162.1 5.47 54.1 0.0722 44.9 0.327 -60.4
4000 0.262 156.8 5.21 51.1 0.0761 44.2 0.318 -62.5
4200 0.270 151.9 4.97 48.1 0.0787 42.6 0.308 -64.8
4400 0.279 147.3 4.75 45.2 0.0831 41.5 0.297 -67.1
4600 0.288 142.9 4.55 42.3 0.0861 40.4 0.289 -69.6
4800 0.296 139.0 4.36 39.4 0.0898 38.9 0.280 -71.9
5000 0.305 135.1 4.19 36.6 0.0925 37.6 0.270 -74.4
5200 0.314 131.7 4.04 33.7 0.0960 36.3 0.261 -76.9
5400 0.323 128.4 3.89 30.9 0.0994 34.8 0.252 -79.5
5600 0.332 125.2 3.76 28.1 0.1020 33.4 0.244 -82.1
5800 0.341 122.0 3.63 25.3 0.1063 31.7 0.235 -84.7
6000 0.349 119.1 3.51 22.5 0.1093 30.2 0.226 -87.3
