HSG1001
Rev.1.00, Apr.08.2004, page 12 of 37
S Parameter
(V
CE
= 1 V, I
C
= 1 mA, Z
O
= 50
Ω
)
S11 S21 S12 S22
f (MHz) MAG ANG MAG ANG MAG ANG MAG ANG
100 0.984 -3.8 3.19 176.5 0.0084 110.0 0.993 -2.3
200 0.981 -7.1 3.20 172.9 0.0100 79.3 0.998 -4.1
300 0.974 -10.1 3.19 169.7 0.0178 88.7 0.992 -6.2
400 0.973 -14.0 3.19 166.7 0.0216 82.4 0.986 -8.2
500 0.968 -17.6 3.20 163.6 0.0275 77.1 0.981 -10.2
600 0.962 -21.0 3.20 160.8 0.0320 76.0 0.974 -12.2
700 0.958 -24.6 3.16 157.7 0.0385 72.5 0.966 -14.2
800 0.951 -28.0 3.14 154.6 0.0427 69.6 0.958 -16.1
900 0.945 -31.7 3.17 152.5 0.0477 67.5 0.948 -17.9
1000 0.936 -35.4 3.16 148.8 0.0519 65.7 0.937 -19.8
1100 0.927 -38.9 3.15 145.9 0.0566 62.8 0.929 -21.6
1200 0.915 -42.7 3.15 142.4 0.0614 60.3 0.917 -23.4
1300 0.907 -46.3 3.11 139.5 0.0656 58.2 0.906 -25.3
1400 0.897 -49.9 3.09 136.7 0.0708 56.1 0.895 -27.0
1500 0.885 -53.8 3.08 133.8 0.0746 53.1 0.884 -28.8
1600 0.871 -57.7 3.08 130.8 0.0780 50.7 0.871 -30.5
1700 0.860 -61.4 3.06 127.8 0.0822 48.5 0.859 -32.3
1800 0.849 -65.1 3.02 124.9 0.0856 45.9 0.847 -33.9
1900 0.836 -69.0 2.99 122.1 0.0885 44.0 0.834 -35.7
2000 0.824 -73.1 2.98 119.3 0.0920 41.8 0.821 -37.4
2200 0.799 -80.8 2.91 113.5 0.0972 37.5 0.796 -40.7
2400 0.775 -88.8 2.86 107.8 0.1015 33.1 0.770 -43.9
2600 0.750 -96.8 2.79 102.3 0.1060 29.2 0.743 -47.0
2800 0.727 -104.9 2.72 96.9 0.1085 25.5 0.717 -50.1
3000 0.704 -112.9 2.66 91.3 0.1105 21.6 0.693 -52.9
3200 0.685 -120.9 2.58 86.1 0.1123 18.5 0.670 -55.9
3400 0.666 -128.8 2.50 81.0 0.1125 14.6 0.648 -58.7
3600 0.651 -136.5 2.42 76.1 0.1123 11.1 0.626 -61.4
3800 0.638 -143.8 2.35 71.3 0.1115 9.1 0.607 -64.1
4000 0.629 -151.2 2.28 66.6 0.1111 5.9 0.590 -66.8
4200 0.619 -158.4 2.21 62.1 0.1102 4.1 0.574 -69.4
4400 0.615 -165.2 2.14 57.6 0.1084 2.0 0.558 -72.0
4600 0.609 -172.0 2.07 53.3 0.1064 0.0 0.544 -74.7
4800 0.606 -178.3 2.00 49.1 0.1057 -1.8 0.530 -77.2
5000 0.605 175.5 1.94 44.9 0.1029 -3.0 0.518 -79.8
5200 0.605 169.4 1.88 40.8 0.1013 -4.0 0.505 -82.4
5400 0.606 163.9 1.82 37.0 0.0995 -5.2 0.495 -85.2
5600 0.607 158.5 1.76 33.1 0.0975 -5.9 0.485 -87.9
5800 0.608 153.2 1.71 29.3 0.0959 -6.6 0.474 -90.7
6000 0.610 148.1 1.66 25.6 0.0946 -6.4 0.463 -93.5
