HSG1001
Rev.1.00, Apr.08.2004, page 34 of 37
Electrical Characteristics on Evaluation Board
(VCC = 2V, IC = 10mA, Ta = 25°C)
Item Symbol Data Unit Test Condition
Noise Figure NF 1.55 dB f = 5.8GHz
Power Gain PG 12.5 dB f = 5.8GHz
Input Return Loss RLin 18.4 dB f = 5.8GHz
Output Return Loss RLout 23.3 dB f = 5.8GHz
1dB Gain Compression P1dB
+
10.5 dBm f = 5.8GHz
Third order intercept point OIP3
+
24 dBm fd = 5.8GHz, fud = 5.801GHz
