HSG1001
Rev.1.00, Apr.08.2004, page 2 of 37
Electrical Characteristics
(Ta = 25°C)
Item Symbol Min Typ Max Unit Test conditions
DC current transfer ratio h
FE
100 200 300

V
CE
= 2 V, I
C
= 5 mA
Reverse Transfer Capacitance C
re

0.08

pF V
CB
= 2 V, I
E
= 0, f = 1 MHz
Transition Frequency f
T

35

GHz V
CE
= 2 V, I
C
= fT peak, f = 1 GHz
Insertion power gain |S21| 2 
19

dB V
CE
= 2 V, I
C
= 5 mA, f = 1.8 GHz

17

V
CE
= 2 V, I
C
= 5 mA, f = 2.4 GHz

11

V
CE
= 2 V, I
C
= 10 mA, f = 5.8 GHz
Maximum Stable Gain Note1 MSG

22

dB V
CE
= 2 V, I
C
= 5 mA, f = 1.8 GHz

21

V
CE
= 2 V, I
C
= 5 mA, f = 2.4 GHz

15

V
CE
= 2 V, I
C
= 10 mA, f = 5.8 GHz
Power Gain PG

19.5

dB V
CE
= 2 V, I
C
= 5 mA, f = 1.8 GHz

18

V
CE
= 2 V, I
C
= 5 mA, f = 2.4 GHz
8.5 11.5

V
CE
= 2 V, I
C
= 10 mA, f = 5.8 GHz
Noise figure NF

0.75

dB V
CE
= 2 V, I
C
= 5 mA, f = 1.8 GHz

0.85

V
CE
= 2 V, I
C
= 5 mA, f = 2.4 GHz

1.3 1.9 V
CE
= 2 V, I
C
= 10 mA, f = 5.8 GHz
Maximum Available Gain
Note2
MAG

13

dB V
CE
= 2 V, I
C
= 10 mA, f = 5.8 GHz
Notes: 1. MSG = |S
21
| / |S
12
|
2. MAG = |S
21
| / |S
12
|(K-(K
2
-1)
1/2
)
