HSG1001
Rev.1.00, Apr.08.2004, page 14 of 37
S Parameter
(V
CE
= 1 V, I
C
= 5 mA, Z
O
= 50
Ω
)
S11 S21 S12 S22
f (MHz) MAG ANG MAG ANG MAG ANG MAG ANG
100 0.926 -6.5 14.38 173.3 0.0091 85.9 0.973 -4.3
200 0.913 -13.1 14.25 167.1 0.0097 99.7 0.982 -8.2
300 0.895 -19.2 14.00 161.3 0.0151 73.8 0.966 -12.1
400 0.874 -25.8 13.73 155.7 0.0209 73.7 0.946 -15.9
500 0.848 -32.1 13.46 150.6 0.0255 69.9 0.924 -19.6
600 0.822 -38.2 13.13 145.6 0.0290 69.7 0.896 -22.8
700 0.795 -43.8 12.66 140.9 0.0331 63.8 0.867 -26.1
800 0.765 -49.5 12.29 136.3 0.0364 60.2 0.837 -29.0
900 0.735 -55.6 12.01 132.1 0.0390 57.2 0.806 -31.6
1000 0.703 -60.9 11.59 127.7 0.0417 56.3 0.777 -34.1
1100 0.672 -66.3 11.18 123.7 0.0445 54.1 0.749 -36.4
1200 0.639 -71.7 10.83 119.6 0.0469 50.4 0.720 -38.4
1300 0.611 -76.5 10.41 115.9 0.0494 50.0 0.694 -40.4
1400 0.585 -81.6 10.01 112.5 0.0516 48.7 0.669 -42.3
1500 0.557 -86.6 9.66 109.1 0.0530 47.2 0.644 -43.9
1600 0.532 -91.6 9.31 105.8 0.0552 44.8 0.621 -45.4
1700 0.510 -96.3 8.96 102.8 0.0564 44.4 0.599 -46.9
1800 0.489 -101.0 8.63 99.9 0.0578 43.2 0.579 -48.3
1900 0.469 -105.7 8.32 97.1 0.0587 42.0 0.559 -49.6
2000 0.451 -110.5 8.03 94.3 0.0604 41.3 0.541 -51.0
2200 0.422 -119.6 7.48 89.2 0.0632 39.7 0.508 -53.4
2400 0.396 -128.7 6.99 84.4 0.0656 38.8 0.478 -55.7
2600 0.379 -137.7 6.55 79.9 0.0681 37.0 0.449 -57.9
2800 0.364 -146.4 6.15 75.6 0.0709 35.7 0.426 -60.2
3000 0.355 -154.7 5.79 71.5 0.0720 34.5 0.404 -62.1
3200 0.349 -162.8 5.46 67.5 0.0745 34.6 0.384 -64.6
3400 0.346 -170.4 5.17 63.7 0.0763 33.5 0.366 -66.9
3600 0.344 -177.6 4.90 60.1 0.0790 32.3 0.347 -68.8
3800 0.345 176.2 4.65 56.7 0.0806 31.9 0.334 -70.9
4000 0.350 170.1 4.44 53.2 0.0841 31.1 0.321 -73.3
4200 0.355 164.3 4.24 49.9 0.0860 30.3 0.308 -75.8
4400 0.360 159.0 4.05 46.6 0.0888 29.5 0.296 -78.2
4600 0.367 153.9 3.88 43.3 0.0910 28.7 0.285 -80.9
4800 0.373 149.2 3.72 40.2 0.0942 27.7 0.274 -83.3
5000 0.381 144.5 3.58 37.0 0.0968 26.5 0.264 -85.9
5200 0.390 140.2 3.44 33.9 0.0995 25.4 0.253 -88.8
5400 0.396 136.3 3.32 30.8 0.1026 24.5 0.244 -91.5
5600 0.404 132.5 3.20 27.8 0.1051 23.6 0.235 -94.2
5800 0.411 128.8 3.09 24.8 0.1081 22.2 0.225 -97.3
6000 0.420 125.3 2.99 21.8 0.1106 21.1 0.216 -100.4
