Renesas HSG1001 - Manual (Page 24)

HSG1001
Rev.1.00, Apr.08.2004, page 24 of 37
S Parameter
(V
CE
= 2 V, I
C
= 20 mA, Z
O
= 50
Ω
)
S11 S21 S12 S22
f (MHz) MAG ANG MAG ANG MAG ANG MAG ANG
100 0.754 -14.4 40.97 166.9 0.0015 90.4 0.956 -8.3
200 0.711 -27.2 39.29 155.2 0.0059 77.2 0.928 -14.6
300 0.655 -38.7 36.61 144.9 0.0095 78.1 0.869 -20.0
400 0.593 -49.1 33.71 136.1 0.0141 65.4 0.808 -24.6
500 0.532 -58.5 30.77 128.4 0.0160 63.9 0.751 -27.9
600 0.477 -66.7 27.97 122.0 0.0184 63.2 0.700 -30.2
700 0.431 -74.1 25.44 116.6 0.0202 62.8 0.656 -32.1
800 0.390 -80.7 23.25 111.8 0.0222 60.3 0.619 -33.3
900 0.352 -87.0 21.35 107.7 0.0232 60.3 0.587 -34.4
1000 0.322 -93.0 19.67 104.0 0.0252 60.4 0.558 -35.2
1100 0.297 -98.8 18.21 100.7 0.0273 58.9 0.535 -35.8
1200 0.274 -104.5 16.94 97.6 0.0286 59.9 0.515 -36.3
1300 0.255 -109.9 15.80 94.9 0.0303 60.5 0.497 -36.9
1400 0.238 -115.4 14.81 92.3 0.0318 60.0 0.480 -37.3
1500 0.225 -121.2 13.93 89.9 0.0335 59.9 0.466 -37.9
1600 0.213 -126.7 13.14 87.6 0.0364 60.9 0.452 -38.4
1700 0.204 -132.3 12.43 85.5 0.0370 59.5 0.440 -38.9
1800 0.197 -137.8 11.80 83.4 0.0390 59.4 0.430 -39.5
1900 0.190 -143.3 11.22 81.4 0.0409 60.5 0.420 -40.1
2000 0.186 -148.8 10.69 79.6 0.0424 59.5 0.410 -40.8
2200 0.181 -159.3 9.77 75.9 0.0461 59.2 0.392 -42.1
2400 0.182 -169.0 8.99 72.5 0.0495 57.6 0.376 -43.6
2600 0.184 -177.8 8.33 69.2 0.0528 55.7 0.362 -45.1
2800 0.189 173.9 7.76 66.0 0.0561 55.8 0.347 -46.8
3000 0.197 166.9 7.25 62.9 0.0604 54.4 0.335 -48.6
3200 0.205 160.7 6.81 59.9 0.0639 53.7 0.322 -50.7
3400 0.215 154.7 6.42 56.9 0.0670 52.3 0.311 -52.7
3600 0.222 149.5 6.06 54.0 0.0701 50.9 0.299 -54.5
3800 0.230 145.4 5.74 51.4 0.0745 50.5 0.291 -56.6
4000 0.241 141.7 5.47 48.6 0.0783 48.9 0.282 -59.1
4200 0.251 138.0 5.21 45.8 0.0823 47.7 0.272 -61.4
4400 0.260 134.5 4.98 43.1 0.0858 45.6 0.263 -64.0
4600 0.271 131.3 4.77 40.4 0.0889 44.0 0.254 -66.5
4800 0.279 128.3 4.58 37.7 0.0929 42.6 0.246 -69.1
5000 0.289 125.3 4.40 35.0 0.0970 41.2 0.237 -71.6
5200 0.298 122.5 4.23 32.3 0.1003 39.3 0.228 -74.2
5400 0.307 119.9 4.08 29.6 0.1046 37.7 0.219 -77.1
5600 0.315 117.3 3.94 26.9 0.1070 36.1 0.212 -79.8
5800 0.325 114.8 3.80 24.3 0.1110 34.4 0.203 -82.7
6000 0.333 112.2 3.68 21.6 0.1145 32.4 0.194 -85.2
