HSG1001
Rev.1.00, Apr.08.2004, page 32 of 37
S Parameter
(V
CE
= 3 V, I
C
= 30 mA, Z
O
= 50
Ω
)
S11 S21 S12 S22
f (MHz) MAG ANG MAG ANG MAG ANG MAG ANG
100 0.660 -18.4 50.17 164.6 0.0059 144.0 0.926 -10.0
200 0.619 -33.3 47.07 151.0 0.0078 69.5 0.897 -15.9
300 0.551 -46.2 42.69 139.5 0.0105 59.6 0.826 -21.5
400 0.487 -57.6 38.24 130.3 0.0127 68.2 0.757 -25.3
500 0.428 -67.1 34.07 122.6 0.0143 66.2 0.700 -28.0
600 0.377 -75.4 30.40 116.5 0.0162 65.2 0.651 -29.6
700 0.337 -82.8 27.27 111.4 0.0180 63.2 0.610 -30.7
800 0.301 -89.6 24.65 107.0 0.0199 63.8 0.577 -31.5
900 0.273 -96.0 22.44 103.2 0.0212 62.9 0.550 -32.0
1000 0.248 -102.6 20.55 99.9 0.0221 64.8 0.527 -32.3
1100 0.228 -108.8 18.93 96.9 0.0247 62.0 0.507 -32.8
1200 0.211 -115.2 17.54 94.1 0.0250 64.0 0.491 -33.1
1300 0.198 -120.4 16.31 91.6 0.0285 63.4 0.476 -33.5
1400 0.186 -126.8 15.25 89.3 0.0303 63.6 0.464 -33.8
1500 0.177 -133.0 14.31 87.1 0.0316 63.8 0.451 -34.4
1600 0.170 -139.0 13.47 85.0 0.0336 64.8 0.441 -34.6
1700 0.165 -144.9 12.73 83.0 0.0351 63.0 0.432 -35.2
1800 0.161 -151.1 12.06 81.1 0.0363 62.4 0.422 -35.7
1900 0.158 -156.5 11.46 79.3 0.0386 63.1 0.414 -36.4
2000 0.158 -162.3 10.91 77.5 0.0405 63.0 0.406 -37.0
2200 0.159 -172.3 9.96 74.1 0.0441 62.0 0.391 -38.3
2400 0.163 178.5 9.16 70.9 0.0476 61.1 0.377 -40.0
2600 0.170 170.7 8.48 67.7 0.0520 60.8 0.364 -41.6
2800 0.178 163.4 7.89 64.7 0.0554 59.7 0.352 -43.1
3000 0.187 157.5 7.38 61.8 0.0593 57.1 0.340 -45.0
3200 0.197 152.0 6.93 58.8 0.0628 56.7 0.328 -47.1
3400 0.208 147.1 6.52 55.9 0.0666 55.1 0.317 -49.3
3600 0.216 142.6 6.16 53.2 0.0695 53.7 0.306 -51.0
3800 0.224 138.8 5.84 50.7 0.0731 52.7 0.299 -53.1
4000 0.235 135.8 5.56 47.9 0.0775 51.4 0.290 -55.7
4200 0.245 132.5 5.30 45.3 0.0812 49.5 0.281 -57.9
4400 0.254 129.5 5.06 42.6 0.0849 48.3 0.273 -60.6
4600 0.265 126.8 4.85 40.0 0.0887 46.3 0.264 -63.0
4800 0.274 124.1 4.65 37.3 0.0922 44.8 0.256 -65.4
5000 0.283 121.4 4.47 34.7 0.0957 43.2 0.247 -67.9
5200 0.292 119.1 4.30 32.0 0.0996 41.5 0.238 -70.6
5400 0.301 116.6 4.15 29.4 0.1036 39.7 0.230 -73.2
5600 0.310 114.1 4.01 26.8 0.1066 37.9 0.222 -75.8
5800 0.319 111.8 3.87 24.2 0.1104 35.8 0.213 -78.3
6000 0.328 109.5 3.74 21.5 0.1138 34.2 0.204 -81.1
