Mechanical specifications, Rsg2288 mechanical dimensions – RuggedCom RUGGEDSWITCH RSG2288 User Manual
Page 35
4. Technical Specifications
RuggedCom® RuggedSwitch®
35
RSG2288 Installation Guide Rev 108
4.9. Mechanical Specifications
Parameter
Value
Comments
Dimensions
18.29 Ч 12.14 Ч 1.75 in
(464.57 Ч 308.36 Ч 44.45 mm)
(Length × Width × Height)
with mounting brackets installed
Weight
10 lb (4.5 kg)
Enclosure
18AWG galvanized steel
Table 4.13. Mechanical Specifications
Figure 4.1. RSG2288 Mechanical Dimensions
