4. Technical Specifications
RuggedCom® RuggedSwitch® 30 RSG2288 Installation Guide Rev 108
4. Technical Specifications
4.1. Power Supply Specifications
Input Range
Power Supply Type
Min Max
Internal Fuse Rating
Max. Power
Consumption
a
12 – 24 VDC 10 VDC 36 VDC 6.3A(F)
b
28 W
48 VDC 36 VDC 59 VDC 3.15A(T)
b
28 W
HI (125/250 VDC)
c
88 VAC 300 VDC 2A(T)
bc
28 W
HI (110/230 VAC)
c
85 VAC 264 VAC 2A(T)
bc
28 W
a
Power consumption varies based on configuration. 10/100Base-TX ports consume roughly 1W less than fiber optic ports.
b
(F) Denotes fast-acting fuse (T) denotes time-delay fuse.
c
The “HI” power supply is the same power supply for both AC and DC.
Table 4.1. Power Supply Specifications
4.2. Failsafe Relay Specifications
Parameter Value (Resistive Load)
Max Switching Voltage 240VAC, 125VDC
Rated Switching Current 2A @ 240VAC, 0.15A @ 125VDC, 2A @ 30VDC
Max Switching Capacity 150W, 500VA
Table 4.2. Failsafe Relay Specifications
4.3. Networking Standards Supported
Parameter Description
IEEE 802.3 10BaseT
IEEE 802.3u 100BaseTX/100BaseFX
IEEE 802.3z 1000BaseSX/LX
IEEE 802.3ab 1000BaseTx
IEEE 802.3x Full Duplex Operation, Flow Control
IEEE 802.1D MAC Bridges
IEEE 802.1Q VLAN (Virtual LAN) Tagging
IEEE 802.1p Class of Service
IEEE 1588 v2 Precision Time Protocol
Table 4.3. Networking Standards Supported
