Re:control M207 User’s Manual
8
1.5.2 The rear side of the Re:control M207
Figure 1-2: Rear view
1. IR Port
You can point the IR port at the IR
receiver of targeted device to
control the unit.
2. Reset switch
You can reset the Re:control M207
while the Re:control M207 can’t
work properly or hang on.
3. Back label
Back label marks the model
number and the briefly
specifications.
4. Buzzer hole
Beeps signal are released from
here.
5. Battery compartment
You can remove the cover to
replace the 3xAAA alkaline
batteries or Ni-MH rechargeable
batteries.
6. Learning eye (P.37)
The Re:control M207 receives the
IR codes from here and saves the
corresponding codes. Makes the
original remote control point at the
Learning eye of the Re:control
M207 and press the corresponding
buttons to send out the IR signals.
In this way, the Re:control M207
will learn the IR codes from your
original device.
