7. Lay a sheet of paper on top of the
master belt [S] (dark green plastic
belt), to avoid damage to the master
belt.
CAUTION:
Do not touch the master belt.
8. Slide the blue plastic corona wire
cleaner [T] from its home position all
the way across to the right side of the
machine. Then move it back to the
home position; you will hear a click
when the cleaner reaches home
position.
CAUTION:
Printout quality may deteriorate if the
cleaner is not at the home position.
9. Remove the sheet of paper from the
master belt, and put back the toner
cassette.
10. Close the front cover.
[S]
[T]
L
O
O
K
IN
G
A
F
T
E
R
T
H
E
M
A
C
H
IN
E
LOOKING AFTER THE MACHINE USER MAINTENANCE PROCEDURES
211
